260mm (33KW-115KW)
Author: admin Viewed: 5136【Close】
2017-08-22 09:58:54
UNITE:MM
Flame size 260mm V2.5 Model Rated
TorqueRated
VoltageRated
SpeedRated
PowerRated
CurrentKt Ke Max.
SpeedMax.
TorqueRotor
InertiaPoles Weight Length N.m Vac rpm kW A N.m/A V/krpm rpm N.m Kg.cm² poles Kg mm 260H30D15C 191 380 1500 30 66 3.2 191 2000 573 348 8 100 442 260H34D17C 191 380 1700 34 74 2.8 170 2300 573 348 8 100 442 260H40D20C 191 380 2000 40 85 2.5 148 2500 573 348 8 100 442 260H33D15C 208 380 1500 33 70 3.3 197 2000 624 430 8 110 457 260H37D17C 208 380 1700 37 79 2.9 173 2300 624 430 8 110 457 260H44D20C 208 380 2000 44 92 2.5 150 2500 624 430 8 110 457 260H41D15C 264 380 1500 41 89 3.2 196 2000 792 546 8 120 457 260H47D17C 264 380 1700 47 100 2.9 175 2300 792 546 8 120 457 260H55D20C 264 380 2000 55 113 2.5 154 2500 792 546 8 120 457 260H50D15C 316 380 1500 50 107 3.2 195 2000 948 644 8 125 542 260H56D17C 316 380 1700 56 123 2.8 171 2300 948 644 8 125 542 260H66D20C 316 380 2000 66 143 2.4 146 2500 948 644 8 125 542 260H60D15C 384 380 1500 60 122 3.4 208 2000 1152 772 8 139 542 260H68D17C 384 380 1700 68 143 3.0 179 2300 1152 772 8 139 542 260H80D20C 384 380 2000 80 171 2.5 149 2500 1152 772 8 139 542 260H75D15C 480 380 1500 75 153 3.4 208 2000 1440 978 8 158 687 260H85D17C 480 380 1700 85 168 3.1 189 2300 1440 978 8 158 687 260H10E20C 480 380 2000 100 211 2.5 151 2500 1440 978 8 158 687 260H90D15C 570 380 1500 90 185 3.4 204 2000 1710 1158 8 175 687 260H10E17C 570 380 1700 100 208 3.0 182 2300 1710 1158 8 175 687 260H11E20C 550 380 2000 115 231 2.6 159 2500 1650 1158 8 175 687 Motor insulation: class-H; Thermal protection: PTC100 with KTYoptional; Protection grade: IP65 except terminal box; Wiring method:Terminal box; Cooling method: liquid cooling; Working standard:long-term, S1 【V2.5】
- 200,260mm servo motor (liquid cooling)
